Enter the IP of the machine control in the Address field. In the Integration Data Sources section of the Add Machine form (or in the Integration Data Sources section of the edit form for existing machines), select Modbus as the integration type. Once a Modbus configuration has been validated in the above steps, it’s time to configure a machine with a Modbus data source in MachineMetrics. This will verify that Modbus is programmed correctly, that data is coming through, and that parameters such as byte order are correctly known.
Use a Modbus client to test reading some of the items in the Modbus map. Your control may support a standard map, or it may require all data to be custom programmed. If you do not know what your Modbus map looks like, consult with your machine tool vendor. A length must be provided with string types. string: A sequence of characters making up a string of text.Types are interpreted by the client, and MachineMetrics supports the following types: Modbus MapĪ Modbus map is a table of data values provided by the Modbus server, where each row lists the address and type of the value.
MODBUS SERVER PORT FULL
It’s common for Modbus devices to operate in either mixed mode, or to utilize only function 3 over its full address space. This scheme limits each function to a range of 10,000 values. Address 40001 - 49999: analog output holding registers (3).Address 30001 - 39999: analog input registers (4).Address 10001 - 19999: discrete input contacts (2).Address 1 - 9999: discrete output coils (1).
A common convention in Modbus addressing, which we refer to as “mixed”, uses part of the address itself to determine which function should be read. Each of these functions has its own address space from 0 - 65535. Modbus supports 4 different read functions: discrete output coils (1), discrete input contacts (2), analog output holding registers (3), and analog input registers (4). Register address space and functions are related concepts. If you see incorrect values when reading 32-bit numbers, this setting might be wrong. It may return the registers in either order. Similarly, to emulate 32-bit integers and floating-point values, Modbus needs to return data in two consecutive registers. If you see incorrect values when reading 16-bit numbers, this setting might be wrong. Each Modbus register is a 16-bit integer, composed of two bytes, and the server may return these bytes in either “little-endian” (low byte first) or “big-endian” (high byte first) order. The server byte and word ordering refer to how a server returns data values. If you know the unit ID is not used in your setup, you can assume the value to be 1.
MODBUS SERVER PORT SERIAL
The unit/device/slave ID is the address of a Modbus device in a chain of serial devices, and will not necessarily be relevant for Modbus-TCP communication.
MODBUS SERVER PORT TRIAL
If you do not have a Modbus client already, you can download one such as the “Simply Modbus TCP Client”, which will run in a trial mode and allow you to perform basic testing. Connect a computer to the same network that the machine control is on, and use a Modbus client to try and open a connection to the Modbus server on the machine. Make sure the TCP port is open on the machine’s firewall if there is one. The TCP port being used by Modbus (usually 502).Once you’ve established that Modbus should be available on your control, you should test communication with it before trying to do any Modbus configuration in MachineMetrics. If you have any uncertainty about the Modbus capabilities of your machine control, please reach out to your vendor to see what options are available to you. It may need to be programmed to provide data.It may need to be loaded as an additional program in the control.It may be an optional component not supported by your machine control or under certain configurations.Some examples of why Modbus may not be readily useable on a control: Some machine controls support running a Modbus server to provide internal data, but may not be configured to do so by default. Modbus TCP Onboarding Topics covered in this article:
